Cardan generators are generators driven by a tractor power take-off that makes it possible to supply energy in places where this latter can be be hardly provided by other vehicles, as for example in the open countryside.
Please browse our catalogue for detailed technical information and for the recommended tractor power.
| MODELLO | POTENZA | TENSIONE | PRESA DI FORZA | DIMENSIONI | PESO | POTENZA TRATTORE | |
|---|---|---|---|---|---|---|---|
| kVA | kW | V | GIRI/MIN | L x La x A (mm) | KG | CV | |
| GP 7 TR-M-C | 6 | 6 | 230 | 430 | 705 x 480 x 810 | 93 | 20 |
| GP 11 TR-M-C | 10 | 10 | 230 | 430 | 705 x 480 x 855 | 113 | 20 |
| GP 11 TR-C | 10 | 8 | 400 / 230 | 430 | 705 x 480 x 855 | 113 | 20 |
| GP 14 TR-C | 12.5 | 10 | 400 / 230 | 430 | 705 x 480 x 855 | 128 | 25 |
| GP 16 TR-C | 15 | 12.8 | 400 / 230 | 430 | 805 x 580 x 915 | 138 | 30 |
| GP 22 TR-C | 20 | 16 | 400 / 230 | 430 | 805 x 580 x 915 | 139 | 40 |
| GP 30 TR-C | 27 | 21.6 | 400 / 230 | 430 | 805 x 580 x 985 | 163 | 60 |
| GP 40 TR-C | 35 | 28 | 400 / 230 | 430 | 805 x 580 x 985 | 175 | 80 |
| MODELLO | POTENZA | TENSIONE | PRESA DI FORZA | DIMENSIONI | PESO | POTENZA TRATTORE | |
|---|---|---|---|---|---|---|---|
| kVA | kW | V | GIRI/MIN | L x La x A (mm) | KG | CV | |
| GP 22 TR/S-C | 20 | 16 | 400 / 230 | 430 | 805 x 580 x 985 | 175 | 40 |
| GP 33 TR/S-C | 30 | 24 | 400 / 230 | 430 | 855 x 580 x 985 | 217 | 60 |
| GP22 TR/S | 20 | 16 | 400 / 230 | 430 | 805 x 580 x 985 | 175 | 40 |
| GP 33 TR/S | 30 | 24 | 400 / 230 | 430 | 855 x 580 x 985 | 217 | 60 |
| GP 50 TR/S | 45 | 36 | 400 / 230 | 430 | 1140 x 750 x 1065 | 357 | 80 |
| GP 55 TR/S | 50 | 40 | 400 / 230 | 430 | 1140 x 750 x1065 | 395 | 100 |
| GP 66 TR/S | 62.5 | 50 | 400 / 230 | 420 | 1140 x 750 x 1065 | 438 | 120 |
| GP 77 TR/S | 75 | 60 | 400 / 230 | 420 | 1140 x 750 x 1065 | 454 | 150 |
| GP 95 TR/S | 87.5 | 70 | 400 / 230 | 420 | 1140 x 750 x 1210 | 506 | 180 |
| GP 95 TR/SF | 87.5 | 70 | 400 / 230 | 835 | 1140 x 750 x 1210 | 506 | 180 |
| GP 115 TR/S | 100 | 80 | 400 / 230 | 420 | 1140 x 750 x 1210 | 572 | 220 |
| GP 115 TR/SF | 100 | 80 | 400 / 230 | 835 | 1140 x 750 x 1210 | 572 | 220 |
